Naxilai Flexible Plastic Transparent Acrylic tube for Lamps
Naxilai Flexible Plastic Transparent Acrylic tube for Lamps
Naxilai Flexible Plastic Transparent Acrylic tube for Lamps
Naxilai Flexible Plastic Transparent Acrylic tube for Lamps
Naxilai Flexible Plastic Transparent Acrylic tube for Lamps
Naxilai Flexible Plastic Transparent Acrylic tube for Lamps
Naxilai Flexible Plastic Transparent Acrylic tube for Lamps
Naxilai Flexible Plastic Transparent Acrylic tube for Lamps
Naxilai Flexible Plastic Transparent Acrylic tube for Lamps
Naxilai Flexible Plastic Transparent Acrylic tube for Lamps
Naxilai Flexible Plastic Transparent Acrylic tube for Lamps
Naxilai Flexible Plastic Transparent Acrylic tube for Lamps
Naxilai Flexible Plastic Transparent Acrylic tube for Lamps

Naxilai Flexible Plastic Transparent Acrylic tube for Lamps

Model NO.
NXL-ECAT245
Delivery:
FOB,CIF,EXW ETC..
Minimum order quantity:
200 pieces
Supply Ability:
10000 pieces / Week
Country of Origin:
Guangzhou,China
Stock Time:
10 Days
Quantity:

Flexible Plastic Transparent Acrylic tube for Lamps

Flexible acrylic tube is also called PMMA tube made of plastic Polymethylmethacrylate which is one kind of plexiglass. It is high shining good transparency.The light transmittance is above 92%. Colored acrylic has a very amazing color effect. It is very easy to process them. Acrylic density is only half of glass. In addition, it is not as fragile as glass. Even if it is broken, it will not be dangerous to hurt people.

available outer diameter sizes (in millimetre)

extruded acrylic tube

5

6

7

8

9

10

11

12

12.5

13

14

15

16

16.5

17

18

19

20

21

22

23

24

25

26

26.5

28

30

32

33

34

35

36

37.5

38

40

42

45

48

50

51

52

54

55

56

57

58

60

62

63

64

65

70

71

72

73

75

76

77

80

82

85

87

90

95

100

105

110

115

120

125

130

135

140

145

150

155

160

165

170

180

190

200

210

220

250

300

350

360

400

extruded screw acrylic tube

9

12

16

19

22

25

28

32

35

38

51

76

90

120

cast acrylic tube in 2000mm long(wall thickness from 4mm to 110mm)

90

95

100

110

120

125

130

140

145

150

160

165

170

180

190

200

210

220

230

240

250

260

270

280

285

290

300

305

310

320

328

240

350

352

360

370

380

390

400

403

420

450

454

478

500

528

532

556

579

600

606

629

650

700

780

800

900

1000

1100

cast acrylic tube in 3000mm long(wall thickness from 4mm to 110mm)

200

250

300

350

400

450

500

550

598

700

800

1000

1200

1500

extruded square acrylic tube

10X10

13X13

17X17

14X24

18X20

15X25

25X25

35X35

50X50

55X55

60X60

65X105

Technical data sheet of PMMA

item

test method

unit

PMMA

color

transparent

porportion

1183

g/cm3

1.2

heat endurance(continuous)

70

heat endurance(short-term)

90

glass transition temperature

100

coefficient of linear thermal expansion(23--100℃ average value)

m/(m.k)

70×10-6

combustibility(UL94)

4589

HB

negative(suck in 23℃ water)

62

%

0.3

bending tensile stress/tensile stress of broken

527

MPa

125

tensilbe modulus of elasticity

527

MPa

3300

friction coefficient

0.55

luo's hardness

2039-1

-

90

resistance strength

60243

kv/mm

>40

volume resistance

(60093)

Ω×cm

≥1015

surface resistance

(60093)

Ω

≥1015

acrylic chandelier tube

Packing:

We adapt reinforced wooden box to pack acrylic tubes mostly which can provide all-round protection for your products during transportation. This shipping method can make sure all acrylic tubes safety and prevent them broken and deformation.

50cm acrylic tubes

acrylic 8 tubes packing

About US

Naxilai has been in acrylic business for more than 15years. The acrylic tubes are made of 100% virgin Mitsubishi pmma which is non-yellow and long service life. We have complete modern equipments like laser cutting machine, engraving machine, cutting machine, circular grinding machine, lathe, extrusion lines, ovens, polishing machines, water tank etc. Therefore, we can build many complicated acrylic products like flange, cone, filter, reaction tank, acrylic hyperbaric oxygen chamber, algae cultivation tubing, acrylic aquarium etc. We also can provide OEM/ODM service. If you need to make acrylic fabrication, please contact with us.

acrylic light tube company

Manufacturing

Our Manufacturing process mainly includes laser cutting, cutting, cloth wheel polishing, diamond polishing, screw drilling, silk screen printing, cleanimg and fabricating.

acrylic tube framed factory

FAQ:

Q: How can I get a sample?

A: Normally small size samples can be sent free of charge and customers only need to pay a little shipping charge or you can provide your DHL, FEDEX, TNT, UPS courier account number to us. As for bigger sizes, it depends.

Q: What is the delivery time?

A: Sample is normally 3 days. Mass production is normally 15days. Mass fabricated products is normally 30days.

Q: How can you guarantee quality of production is the same with sample sent to me before?

A: Our warehouse staff will keep one same sample marked your company name in our factory, production will based on warehouse sample. And we will send you pictures and video if production is finished.

Q: What is the payment term?

A: Normally 30% deposit and 70% balance paid before shipment.

Q: What is the paying ways available?

A: L/C, credit card, T/T, Paypal, Alipay etc.

Q: What is transportation way?

A: Express, by sea, by air, by sea, by express etc.
