We have the large stock for clear acrylic tube.
Because acrylic has high light transmission.They are mostly be used in lighting applications. More and more customers use acrylic tube instead of glass tube.
There are extruded acrylic tube and cast acrylic tube in producing way.
Cast acrylic tube is more expensive than extruded tubing because the way cast pipe is manufactured which involved more labor. Cast clear acrylic pipe is made by mould of 2meters or 3meters long. Then adjust down to the exact inner and out diameters. After that, polishing clear perspex tubing to optical clarity. If you try to make pressure vessels and other equipment. Cast pmma seamless tubing is the correct choice for u.
| available outer diameter sizes (in millimetre) | |||||||||||||
| extruded acrylic tube | |||||||||||||
| 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 | 12.5 | 13 | 14 | 15 | 16 | 16.5 |
| 17 | 18 | 19 | 20 | 21 | 22 | 23 | 24 | 25 | 26 | 26.5 | 28 | 30 | 32 |
| 33 | 34 | 35 | 36 | 37.5 | 38 | 40 | 42 | 45 | 48 | 50 | 51 | 52 | 54 |
| 55 | 56 | 57 | 58 | 60 | 62 | 63 | 64 | 65 | 70 | 71 | 72 | 73 | 75 |
| 76 | 77 | 80 | 82 | 85 | 87 | 90 | 95 | 100 | 105 | 110 | 115 | 120 | 125 |
| 130 | 135 | 140 | 145 | 150 | 155 | 160 | 165 | 170 | 180 | 190 | 200 | 210 | 220 |
| 250 | 300 | 350 | 360 | 400 | |||||||||
| extruded screw acrylic tube | |||||||||||||
| 9 | 12 | 16 | 19 | 22 | 25 | 28 | 32 | 35 | 38 | 51 | 76 | 90 | 120 |
| cast acrylic tube in 2000mm long（wall thickness from 4mm to 110mm) | |||||||||||||
| 90 | 95 | 100 | 110 | 120 | 125 | 130 | 140 | 145 | 150 | 160 | 165 | 170 | 180 |
| 190 | 200 | 210 | 220 | 230 | 240 | 250 | 260 | 270 | 280 | 285 | 290 | 300 | 305 |
| 310 | 320 | 328 | 240 | 350 | 352 | 360 | 370 | 380 | 390 | 400 | 403 | 420 | 450 |
| 454 | 478 | 500 | 528 | 532 | 556 | 579 | 600 | 606 | 629 | 650 | 700 | 780 | 800 |
| 900 | 1000 | 1100 | |||||||||||
| cast acrylic tube in 3000mm long（wall thickness from 4mm to 110mm) | |||||||||||||
| 200 | 250 | 300 | 350 | 400 | 450 | 500 | 550 | 598 | 700 | 800 | 1000 | 1200 | 1500 |
| extruded square acrylic tube | |||||||||||||
| 10X10 | 13X13 | 17X17 | 14X24 | 18X20 | 15X25 | 25X25 | 35X35 | 50X50 | 55X55 | 60X60 | 65X105 | ||
| Technical data sheet of PMMA | |||
| item | test method | unit | PMMA |
| color | transparent | ||
| porportion | 1183 | g/cm3 | 1.2 |
| heat endurance(continuous) | ℃ | 70 | |
| heat endurance(short-term) | ℃ | 90 | |
| glass transition temperature | ℃ | 100 | |
| coefficient of linear thermal expansion(23--100℃ average value) | m/(m.k) | 70×10-6 | |
| combustibility(UL94) | 4589 | HB | |
| negative(suck in 23℃ water) | 62 | % | 0.3 |
| bending tensile stress/tensile stress of broken | 527 | MPa | 125 |
| tensilbe modulus of elasticity | 527 | MPa | 3300 |
| friction coefficient | 0.55 | ||
| luo's hardness | 2039-1 | - | 90 |
| resistance strength | 60243 | kv/mm | >40 |
| volume resistance | （60093） | Ω×cm | ≥1015 |
| surface resistance | （60093） | Ω | ≥1015 |
Packing:
We adapt reinforced wooden box with pallet. which can provide all-round protection for your products during transportation.This shipping method can make sure all Acrylic products safety and revent pressure loss and deformation.
About US
Naxilai has been in acrylic business for more than 15years.The acrylic tubes are made of 100% virgin Mitsubishi pmma which is non-yellow and long service life. We have complete modern equipments like laser cutting machine, engraving machine, cutting machine, circular grinding machine, lathe,extrusion lines, ovens, polishing machines, water tank etc. Therefore, we can build many complicated acrylic products like flange, cone, filter, reaction tank, acrylic hyperbaric oxygen chamber, algae cultivation tubing,acrylic aquarium etc.We also can provide OEM service. If you need to make acrylic fabrication, please contact with us.
Manufacturing
Our Manufacturing process mainly includes laser cutting, cutting, cloth wheel polishing, diamond polishing, screw drilling, silk screen printing, cleanimg and fabricating.
