Naxilai Cut Acrylic Tube
The acrylic clear tube pipe is Polymethylmethacrylate (PMMA).One kind of plexiglass looks very shining. Good transparency. 92% light transmittance , soft light. Looks like glass but only half weight of glass.
Features:
It is plastic and has strong weather resistance, strong hardness and high temperature resistance.Heat endurance is from 70 to 90 degree C.wear resistance, stability and corrosion resistance.
Machining:punching, cuting, thermoforming, drilling, polishing, chamfer angle, glue or other machanical processings.
Application:
LED lighting, acrylic aquarium, acrylic tube fountain, acrylic hyperbaric oxygen chamber, acrylic fish aquarium tank, acrylic stand, acrylic plinth, acrylic display, acrylic vase, acrylic tank, acrylic display case, acrylic lamp, acrylic standee, colored acrylic drum set, acrylic flower stand, acrylic cake stand, acrylic riser, acrylic scrunchie holder, pet cage, candy dispensers, children toys, scientific equiment, structurall support , algae cultivation tubing, seaweed farming tube etc..
Shape of naxilai acrylic tubes:
Round acrylic tube, square acrylic tube, swirl acrylic tube.
Outer diameter available in following chart and Length can be customized.
available outer diameter sizes (in millimetre) |
extruded acrylic tube |
5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 | 12.5 | 13 | 14 | 15 | 16 | 16.5 |
17 | 18 | 19 | 20 | 21 | 22 | 23 | 24 | 25 | 26 | 26.5 | 28 | 30 | 32 |
33 | 34 | 35 | 36 | 37.5 | 38 | 40 | 42 | 45 | 48 | 50 | 51 | 52 | 54 |
55 | 56 | 57 | 58 | 60 | 62 | 63 | 64 | 65 | 70 | 71 | 72 | 73 | 75 |
76 | 77 | 80 | 82 | 85 | 87 | 90 | 95 | 100 | 105 | 110 | 115 | 120 | 125 |
130 | 135 | 140 | 145 | 150 | 155 | 160 | 165 | 170 | 180 | 190 | 200 | 210 | 220 |
250 | 300 | 350 | 360 | 400 | | | | | | | | | |
|
extruded swirl acrylic tube |
9 | 12 | 16 | 19 | 22 | 25 | 28 | 32 | 35 | 38 | 51 | 76 | 90 | 120 |
|
cast acrylic tube in 2000mm long(wall thickness from 4mm to 110mm) |
90 | 95 | 100 | 110 | 120 | 125 | 130 | 140 | 145 | 150 | 160 | 165 | 170 | 180 |
190 | 200 | 210 | 220 | 230 | 240 | 250 | 260 | 270 | 280 | 285 | 290 | 300 | 305 |
310 | 320 | 328 | 240 | 350 | 352 | 360 | 370 | 380 | 390 | 400 | 403 | 420 | 450 |
454 | 478 | 500 | 528 | 532 | 556 | 579 | 600 | 606 | 629 | 650 | 700 | 780 | 800 |
900 | 1000 | 1100 | | | | | | | | | | | |
|
cast acrylic tube in 3000mm long(wall thickness from 4mm to 110mm) |
200 | 250 | 300 | 350 | 400 | 450 | 500 | 550 | 598 | 700 | 800 | 1000 | 1200 | 1500 |
|
extruded square acrylic tube |
10X10 | 13X13 | 17X17 | 14X24 | 18X20 | 15X25 | 25X25 | 35X35 | 50X50 | 55X55 | 60X60 | 65X105 | | |
Manufacturing
Our Manufacturing process mainly includes laser cutting, cutting, cloth wheel polishing, diamond polishing, screw drilling, silk screen printing, cleanimg and fabricating.

FAQ:
Q: How can I get a sample?
A: Normally small size samples can be sent free of charge and customers only need to pay a little shipping charge or you can provide your DHL, FEDEX, TNT, UPS courier account number to us. As for bigger sizes, it depends.
Q: What is the delivery time?
A: Sample is normally 3 days. Mass production is normally 15days. Mass fabricated products is normally 30days.
Q: How can you guarantee quality of production is the same with sample sent to me before?
A: Our warehouse staff will keep one same sample marked your company name in our factory, production will based on warehouse sample. And we will send you pictures and video if production is finished.
Q: What is the payment term?
A: Normally 30% deposit and 70% balance paid before shipment.
Q: What is the paying ways available?
A: L/C, credit card, T/T, Paypal, Alipay etc.
Q: What is transportation way?
A: Express, by sea, by air, by sea, by express etc.
